表1 A系列冻干设备型号及主要性能参数
| 基本型号 Model | 工业化生产用标准型 Combination type for industrialized production | |||||
| 技术指标 Specifications |
A50 |
A75 |
A100 |
A125 |
A150 |
A200 |
| 加热板名义面积 m2 |
50 |
75 |
100 |
125 |
150 |
200 |
| Nominal area of heating plates (m2) | ||||||
| 设计最大捕水能力kg/h |
115 |
175 |
230 |
280 |
340 |
450 |
| Max.design water trapping capability （kg/h) | ||||||
| 加热板温调节范围 |
30-120 |
30-120 |
30-120 |
30-120 |
30-120 |
30-120 |
| Operating temperature of heating plates | ||||||
| 正常最低工作压力 Pa |
45 |
45 |
45 |
45 |
45 |
45 |
| Normal min. Working pressure(Pa) | ||||||
| 空载抽空时间 min |
5 |
8 |
12 |
15 |
15 |
15 |
| Evacuaired time with empty loading(min) | ||||||
| 配套冷量 kw |
85 |
132 |
180 |
217 |
265 |
350 |
| Required cold capacity(kw) | ||||||
| 最大蒸汽耗量（0.7MPa)kg/h |
135 |
200 |
240 |
290 |
350 |
480 |
| Max.vapor consumption (MPa)kg/h | ||||||
| 装机功率 kw |
55 |
68 |
86 |
94 |
105 |
135 |
| Installation power (kw) | ||||||
表2 A系列冻干设备组合型号及主要性能参数
| 基本型号 Model | 工业化生产用组合型 Combination type for industrialized production | |||||
| 技术指标 Specifications |
2×A50 |
2×A75 |
2×A100 |
2×A125 |
2×A150 |
2×A200 |
| 加热板名义面积 m2 |
100 |
150 |
200 |
250 |
300 |
400 |
| Nominal area of heating plates (m2) | ||||||
| 设计最大捕水能力kg/h |
230 |
350 |
460 |
560 |
680 |
900 |
| Max.design water trapping capability （kg/h) | ||||||
| 加热板温调节范围 |
30-120 |
30-120 |
30-120 |
30-120 |
30-120 |
30-120 |
| Operating temperature of heating plates | ||||||
| 正常最低工作压力 Pa |
45 |
45 |
45 |
45 |
45 |
45 |
| Normal min. Working pressure(Pa) | ||||||
| 空载抽空时间 min |
5 |
8 |
12 |
15 |
15 |
15 |
| Evacuaired time with empty loading(min) | ||||||
| 配套冷量 kw |
158 |
240 |
320 |
360 |
480 |
650 |
| Required cold capacity(kw) | ||||||
| 最大蒸汽耗量（0.7MPa)kg/h |
220 |
360 |
480 |
540 |
720 |
960 |
| Max.vapor consumption (MPa)kg/h | ||||||
| 装机功率 kw |
89 |
90 |
115 |
115 |
1269 |
165 |
| Installation power (kw) | ||||||
| 经济组合型式 | (2*BS-FD-50/75/100/125/150/200) (4*BS-FD-50/75/100/125/150/200) | |||||
| Economic combination type | (6*BS-FD-50/75/100/125/150/200) (8*BS-FD-50/75/100/125/150/200) | |||||
| 注:不同的经济组合技术指标会有所不同,4×或6×或8×等越多组合能耗指标会越低。 | ||||||
